Wet Process Heating and Cooling Equipment |
|
||
| WATTS | VOLTS |
HORIZ. In./(mm) |
STD.
VERT.* In./(mm) |
STEEL | 304 ST. STEEL | 316 ST. STEEL | TITANIUM | SHIP
WGT. Lbs./(kg) |
| 3000 | 240 480 |
13 (330) |
15 (380) |
3LP3213-R*-** 3LP3413-R*-** |
3LF3213-R*-** 3LF3413-R*-** |
3LS3213-R*-** 3LS3413-R*-** |
3LT3213-R*-** 3LT3413-R*-** |
30 (14) |
| 6000 | 240 480 |
17 (430) |
37 (940) |
3LP6217-R*-** 3LP6417-R*-** |
3LF6217-R*-** 3LF6417-R*-** |
3LS6217-R*-** 3LS6417-R*-** |
3LT6217-R*-** 3LT6417-R*-** |
33 (15) |
| 9000 | 240 480 |
22 (560) |
37 (940) |
3LP9222-R*-** 3LP9422-R*-** |
3LF9222-R*-** 3LF9422-R*-** |
3LS9222-R*-** 3LS9422-R*-** |
3LT9222-R*-** 3LT9422-R*-** |
36 (16.5) |
| 12000 | 240 480 |
26 (660) |
37 (940) |
3LP12226-R*-** 3LP12426-R*-** |
3LF12226-R*-** 3LF12426-R*-** |
3LS12226-R*-** 3LS12426-R*-** |
3LT12226-R*-** 3LT12426-R*-** |
39 (18) |
| 15000 | 240 480 |
31 (790) |
37 (940) |
3LP15231-R*-** 3LP15431-R*-** |
3LF15231-R*-** 3LF15431-R*-** |
3LS15231-R*-** 3LS15431-R*-** |
3LT15231-R*-** 3LT15431-R*-** |
42 (19) |
| 18000 | 240 480 |
36 (915) |
50 (1270) |
3LP18236-R*-** 3LP18436-R*-** |
3LF18236-R*-** 3LF18436-R*-** |
3LS18236-R*-** 3LS18436-R*-** |
3LT18236-R*-** 3LT18436-R*-** |
45 (20.5) |
| 24000 | 240 480 |
44 (1120) |
50 (1270) |
3LP24244-R*-** 3LP24444-R*-** |
3LF24244-R*-** 3LF24444-R*-** |
3LS24244-R*-** 3LS24444-R*-** |
3LT24244-R*-** 3LT24444-R*-** |
54 (24.5) |
| 27000 | 480 | 50 (1270) |
50 (1270) |
3LP27450-R*-** | 3LF27450-R*-** | 3LS27450-R*-** | 3LT27450-R*-** | 60 (27.5) |
| 30000 | 480 | 55 (1400) |
50 (1270) |
3LP30455-R*-** | 3LF30455-R*-** | 3LS30455-R*-** | 3LT30455-R*-** | 66 (30) |
| 36000 | 480 | 64 (1625) |
50 (1270) |
3LP36464-R*-** | 3LF36464-R*-** | 3LS36464-R*-** | 3LT36464-R*-** | 75 (34) |
| *Specify vertical length by
adding height in inches after "-R". Example: 3LS6217-R39-P1. Three
phase standard, single phase available as option. Specify vertical length (riser
height) greater than or equal to tank depth. ** Thermal Overload Protection |
||||||||
Product Features and Benefits:
SUPERIOR CHEMICAL RESISTANCE: Materials available for use in most aqueous alkaline solutions, plating solutions, and rinse tanks. Check solution recommendation chart or with your chemical supplier for proper sheath material selection.
RUGGED CONSTRUCTION: Heavy wall metal sheaths available in:
• Steel. • 304 stainless steel. • 316 stainless steel.
• Titanium. OUTSTANDING PERFORMANCE: Watt densities of 35 watts per square inch (5.4 w/cm2) extend long service life. Two-inch sludge legs standard, other lengths available.
EVEN HEATING: Bottom design for even heating and varying liquid levels.
CORROSION RESISTANT HEAD: Vapor resistant, flame retardant polypropylene terminal enclosure with 3-foot (.9m) flexible PVC liquid tight conduit.
SAFETY FEATURES:
• Grounded construction. • Thermal protector built in. Replaceable P1 protector standard for solutions up to 180°F (82°C). • Non-floating construction. CERTIFICATIONS: UL listed (except steel) to U.S. and Canadian safety requirements, and CE.
SIZES: 3,000 watts to 36,000 watts.
VOLTAGES: 120 to 600 volts. Three phase standard, single phase available.
OPTIONS AVAILABLE (consult factory):
• Replaceable thermal protectors:
• P4: for solutions from 180°F (82°C) to 230°F (110°C).
• P5: for solutions from 230°F (110°C) to 300°F (150°C).• Resettable thermal protectors:
• P2: for solutions up to 180°F (82°C).
• P6: for solutions from 180°F (82°C) to 230°F (110°C).• Special configurations and vertical lengths. • Longer wire and conduit lengths. • Longer sludge legs. • Flexible risers (available with P2 thermal protectors only.) • Lower watt densities for highly viscous solutions. • Temperature and level controls sized to match the heater. DOWNLOAD THE INFORMATION SHEET (including dimensional diagram)
